Rev9 Hyper Street II Coilover 32way Audi A6 C7 12-18, A7 Quattro
Rev9 Hyper Street II Coilover 32way Audi A6 C7 12-18, A7 Quattro
SKU:R9-HS2-093
In stock
Regular price
$532.00 USD
Regular price
$625.88 USD
Sale price
$532.00 USD
Unit price
/
per
Shipping calculated at checkout.
Free shipping lower 48 states!
Couldn't load pickup availability
New in Box: Rev9 Hyper Street II Coilover
Application:
Audi A7 Quattro (4G8) 12-18
Audi A6/A6 Quattro 12-18
Note: Will not fit Electronic Suspension
Note: Will not fit A7 FWD
Hyper-Street II coilover suspension upgrade features mono-tube shocks with 32 clicks rebound settings and full length adjustable. Mono-tube shocks provides larger capacity for gas and oil to improve comfortable level of typical lowering vehicle. Special 32 clicks of valving allows user to fine tune rebound force settings. Independent spring tension and full length adjustable allows drop without sacrifice comfort by shorten pitch distance.
- Full Steel Alloy Constructions With Aluminum Hardware
- Mono-Tube Shocks Provide Larger Capacity of Oil And Gas
- 32 Clicks of Rebound Force Adjustment
- Full Length Adjustment - Lowers The Car Without Ruining Spring Tension
- Independent Spring Tension - Custom Stiffness Without Change Ride Height
Damping Levels | 32 Levels |
---|---|
Height Adjustment | Yes |
Spring Rate(Front) | 11 kg/mm (616 lbs/inch) |
Spring Rate(Rear) | 8 kg/mm (448 lbs/inch) |
Spring Length(Front) | 210 mm |
Spring Length(Rear) | 220 mm |
Camber Plate(Front) | No |
Camber Plate(Rear) | No |
Spring Inner Diameter(Front) | 62 mm (2.44 inch) |
Spring Inner Diameter(Rear) | 62 mm (2.44 inch) |
Rev9 Coilover Adjustment Quick Guide:
